Continuous Acid Mixing Unit

Totally enclosed acid mixing system: the closed acid mixing tank realizes the totally enclosed acid mixing, which reduces the diffusion of acid mist to the maximum extent;

Description

Features

⊙ Totally enclosed acid mixing system: the closed acid mixing tank realizes the totally enclosed acid mixing, which reduces the diffusion of acid mist to the maximum extent;


⊙ Multiple demist plans: the spray-type and alkali reaction type demist systems remove the acid mist greatly;


⊙ Multiple acid-resisting processes such as PTFE and FRP ensure the equipment durability;


⊙ High automation realizes the automatic control of chemical additive concentration, acid mixing concentration and acid tank level.


Specifications

Model GYC100
Carrier Truck
Truck Chassis Sinotruck
Engine CAT C15
Water Centrifugal Pump IHF200-150-315
Acid Supply Centrifugal Pump ACP-TL150-25
Discharge Centrifugal Pump 10×8×14-14
Max. Discharge Flowrate 2,650 gpm (10 m³/min)
Chemical Additive Transfer Pump 3
Dry Powder Conveyor Qty. 2
Acid Mixing Tank 660 gal (2.5 m³)
Control Mode Auto / Manual
