Coiled Tubing Lifting Frame
The coiled tubing lifting frame, also known as the tension frame, is designed for use in semisubmersible ships or drilling ships. Its upper part is connected to the top drive system, and the lower part is connected to the production test tree or wellhead assembly, which has the role of lifting and carrying the weight of the standpipe system. The frame is equipped with an injector platform, which is convenient for the injector installation and removal from the wellhead, providing a safe working space for coiled tubing operations and greatly improving production efficiency.
