Major Parameters

Daily design fueling flow

5,000~30,000Nm³/d

Plunger pump flow

1,000~2,500L/ h

Gasification capacity

1,000~2,500Nm³/h

LNG storage tank capacity

60~180m³

Design pressure for storage tank

1.44MPa

Max. working pressure for storage tank

1.2MPa

Max. working pressure for pipelines

1.6MPa (LNG), 25MPa (CNG)

Fueling metering accuracy

±1.0 %

Fueling time per vehicle

2~4min

Noise

＜ 75dB（A）

Power

30~100kW

Major Configuration

LNG storage tank ( sets )

1~3（60m³ per unit ）

LNG plunger pump ( sets )

2~4

CNG dispenser ( sets )

2~6

High pressure vaporizer

2~4

Control System

PLC programmable control system

Instrument Air System

Air compressor, Dryer, Buffer tank, etc.
