Volume

50 m³(315 bbl)

Average Discharge Rate

≥1.5 t/min (3,306 lb/min)

Design Pressure

0.3 MPa (43.5 psi)

Residual Rate

≤1%

Dimensions

Φ3,200×8,500 mm (Φ10.5×27.9 ft)

Weight

8,600 kg (18,959 lb)

Volume

35 m³ (220 bbl)

Average Discharge Rate

≥1.2 t/min (2,645 lb/min)

Design Pressure

0.3 MPa (43.5 psi)

Residual Rate

≤0.3%

Dimensions

11,000×2,600×4,200 mm (36.1×8.5×13.8 ft）

Weight

45,000 kg (99,208 lb)

Components

HPHT Consistometer

Ultrasonic Static Gel Strength Analyzer

Atmospheric Consistometer

Pressurized Curing Chamber

Strength Curing Box

HPHT Filter Press

Constant Speed Mixer

Compressive Strength Tester

Dimensions

12,000×3,000×2,900 mm (39.4×9.8×9.5 ft)

Weight

8,500 kg (18,739 lb)

Volume

2 m³ (12 bbl)

Average Discharge Rate

≥1.5 t/min (3,306 lb/min)

Design Pressure

0.25 MPa (36 psi)

Residual Rate

≤1%

Dimensions

2,500×1,600×3,900 mm

(8.2×5.2×12.8 ft)

Weight

3,500 kg (7716 lb)

Chassis

Three-Axle Single Drop

Mixing Tank

2×10 m³ (2×63 bbl）

Dust Removal Tank

10 m³ (63 bbl）

Chemicals Filling Tank

1.5 m³ (9.4 bbl）

Max. Mixing Capacity

20 t/h (728 lb/min)

Working Pressure

0.2~0.3 MPa (29~44 psi)

Residual Rate

≤1%

Dimensions

14,000×2,800×4,300 mm

 (45.9×9.2×14.1 ft)

Weight

23,000 kg (50,706 lb)

Hardware System

HMI simulation system

Main control console input simulation system

Displacement tank simulation system

Slurry mixing tank simulation system

Student End

3D Virtual interactive system

Operation procedure guidance system

Course training system

Examination system

Troubleshooting system

Alarm system

Teacher End

Management system

Operation monitoring system

Fault setting system
